SEA FURY.
! 4) Carefully slide the two wing halves
together and firmly press them together,
allowing the excess epoxy to run out. There
should not be any gap in the wing halves. Use
rubbing alcohol and a paper tower to clean up
any excess epoxy.
! 5) Apply masking tape at the wing join to
hold the wing halves together securely.
Masking tape.

INSTALLING THE AILERON SERVOS.

Servos.
14
Epoxy.
Small weight.
Thread.
Instruction Manual.
We recommended to use long servos
arm for all servos without throttle servo.
! 1) Install the rubber grommets and brass
collets onto the aileron servo. Test fit the servo
into the aileron servo mount.
Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
! 2) Secure the servos with the screws pro-
vided from your radio system.
Using a small weight (
) and thread, feed the string through
works well
the wing as indicated.
Small weight.
Electric wire.
Weighted fuel pick-up
Thread.
Wing bottom.
Thread.
