EXTRA 300S

FUEL TANK INSTALLATION.

Plastic tape.
You should mark which tube is the vent
and which is the fuel pickup when you
attach fuel tubing to the tubes in the stopper.
Once the tank is installed inside the fuselage,
it may be difficult to determine which is which.
Rubber band.
Fuel pick-up
tube.
Blow through one of the lines to ensure
the fuel lines have not become kinked in-
side the fuel tank compartment. Air should
flow through easily.
WHEEL AND WHEEL PANTS INSTALLA-
TION.
1) Assemble and mounting the wheel pants
as shown in the following pictures.
6
installation:
Fuel tank.
Vent tube.
cutting and cut-off wheel.
Fuel fill tube.
wear protective goggles.
Instruction Manual
2) Follow diagram below for wheel pant
Wheel Collar.
Axle.
Wheel.
3) You have to trim each axle using a tool
Caution when cutting the axles and
46mm
(2) Washer.
Nut.
Nut.
Landing Gear.
Wheel Pant.
