Seagull Models Spitfire Mk IX Assembly Manual page 6

SPITFIRE - 2030 mm
INSTALLING THE SWITCH RECEIVER
Install the switch into the precut hole in the
side, in the fuselage.
Trim and cut.
Switch.
INSTALLING THE SWITCH ENGINE
Trim and cut.
6
3/ 32" Hole.
Instruction Manual.
Switch.
INSTALLING THE STOPPER ASSEMBLY.
1) Using a modeling knife, carefully cut
off the rear portion of one of the 3 nylon tubes
leaving 1/2" protruding from the rear of the
stopper. This will be the fuel pick up tube.
2) Using a modeling knife, cut one length
of silicon fuel line. Connect one end of the line
to the weighted fuel pick up and the other end
to the nylon pick up tube.
Balsa
