Seagull Models Spitfire Mk IX Assembly Manual page 10

SPITFIRE - 2030 mm
8) Reinstall the servo horn by sliding the
connector over the pushrod wire. Center the
throttle stick and trim and install the servo horn
perpendicular to the servo center line.
9) Move the throttle stick to the closed position
and move the carburetor to closed. Use a 2.5mm
hex wrench to tighten the screw that secures
the throttle pushrod wire. Make sure to use
threadlock on the screw so it does not vibrate
loose.
Screw.
10
Instruction Manual.
Secure the ignition module in the fuselage
using hood and loop tape. Route the wires as
neccessary, making sure to connect the lead
from the ignition switch and the sensor from
the engine. The lead for the plug is routed
through the opening in the firewall.
Pass the lead for the ignition through the
rectangular hole in the firewall. Connect to the
corresponding lead from the ignition module.
COWLING.
1)Slide the fiberglass cowl over the engine
and line up the back edge of the cowl with the
marks you made on the fuselage then trim and
cut as shown.
Trim and cut.
Trim and cut.
