Configuration Manual
Ascom d62 DECT Handset
5.9

In Call Menu

In Call Menu is a configurable menu in the handset. The purpose of the In Call Menu is to
provide a user friendly access to system dependent functionality during a call such as:
• Start a new call during a conversation
• Switch between calls
• End a call
• Transfer a call
• Transfer to a new call
• Make a conference call
• Activate call back
• Sending call waiting
• Open Contacts (that is, Local phonebook and Company phonebook)
• Send DTMF
• Viewing DECT information
• Turning microphone on/off
Tip: It is also possible to configure own In call functions, see
Functions on page 23, or create a shortcut to a certain In call function, see
a Soft Key to an In Call Function
The menu is described in User Manual, Ascom d62 DECT Handset, TD 92477GB.
The programming of the menu is done with PDM. For instructions on how to work with PDM,
see Installation and Operation Manual, Portable Device Manager (PDM), Windows Version,
TD 92325EN.
Using the PDM and the "Edit template" feature, the parameter can be found at
Systems > System X > PBX Settings > In call functionality
Ask your supplier for example templates that will configure the in call menu for your PBX.
5.9.1 Configure Own In Call Functions
Besides the default In call functions, it is possible to define 10 extra system specific call
services by codes. The codes can be programmed with digits 0-9, #, *, P – pause, H – hook
(auto disconnection), U – the handset prompts for user input with the possibility to enter
numerical characters (procedure call)
1 Select Systems > System X > PBX Settings > In call functionality > General purpose X
2 In the Name field, enter the name to be displayed in the In call menu.
3 In the Data field, enter the applicable code to be used for the function.
4 Click "OK" to save the settings.
Tip: Your supplier may have a template example that will configure the In call functions
menu for the PBX.
5.9.2 Create/Hide a Soft Key to an In Call Function
It is possible to configure the left Soft key or right Soft key as a shortcut to a certain In call
function, or hide the Soft keys. By default, the left Soft key is configured as a loudspeaker
key, and the right Soft key is configured as R-key.
1.This option will be visible in the handset when the parameters "New call" and "Transfer" are set.
2.This option will be visible in the handset when the Admin Menu is activated. See
3.This option is always visible in the handset and cannot be disabled.
25 November 2011 / Ver. E
1
2
3
on page 23.
TD 92639EN
5.9.1 Configure Own In Call
5.9.2 Create/Hide
6 Administration on page 48.
23
