Configuration Manual
Ascom d62 DECT Handset
Note: If no messages have been read/closed manually and TTP expired for each message, a
dialogue window New messages(s): [number of messages]. View now? is displayed. All
messages are indicated as unread messages in the Messaging Inbox.
Example 4
This example describes the message handling with the following message settings:
• TTP= No prioritization
• TTR= Close manually
Tip: It is recommended to use this settings if messages regardless of priority shall be read in
chronological order, that is, the newest message shall be displayed first.
Prio 1
13:59
Figure 8. Display messages in order regardless of priority
In figure 8, a message with priority 1 is received at 13:59. Another message with priority 2
is received at 14:02 and will be displayed. The message with priority 1 is put in the message
queue. The user needs to close the current message (priority 2) to show the message
(priority 1) in the queue. When closing the message (priority 2) it will be indicated as a read
message in the Messaging Inbox.
5.26.3 Broadcast and Multicast Messaging
This feature is supported by d62, but no parameter settings are required.

5.27 Services

Note: This feature is applicable for d62 Messenger and d62 Protector only.
From PDM/IMS3, it is possible to configure up to 10 services that can be reached from the
Services menu. It is also possible to configure soft keys to reach services quickly. A list of
predefined functions are available such as Phone call, Send message and Send data.
5.27.1 Add Service
1 Select "Services".
2 Select the service (1 - 10) to be configured.
3 In the Name field, enter the name of the service. It will be displayed in the telephone.
25 November 2011 / Ver. E
New messages
Prio 2
14:02
Prio 1
13:59
Prio 1
13:59
The user closes
the message
Messaging Inbox
Prio 2
14:02
Prio 2
Prio 1 14:02
13:59
TD 92639EN
39
