Actions When Handset Placed In Charger - ASCOM d62 Configuration Manual

Configuration Manual
Ascom d62 DECT Handset

5.15 Actions when Handset Placed in Charger

5.15.1 In Charger Action when not in Call
The handset can be configured to perform an action when it is placed in a charger. The
selected action is only performed when no call is established. When the handset is removed
from the charger, it returns to previous settings. Note: If the Logout action is enabled, the
handset needs to be logged in manually when it is removed from the charger.
1 Select Connections > In Charger
2 In the In charger action drop-down list, select one of the following:
• No action - no action will be performed when telephone is placed in charger
• Switch off - the telephone will be switched off when placed in charger
• Redirect - the telephone will redirects all calls and messages (d62 Messenger and
d62 Protector only) when placed in charger. Note: The destination number must
be programmed in the PBX to be able to redirect calls/messages
• Sound off - the telephone will be silenced when placed in charger
• Logout - the handset will be logged out when placed in charger. This option is only
performed if the license dependent Shared Phone feature is enabled.
• Message absence - if a message is sent from a system, it will be notified that the
handset is absence.
• Change profile - the handset will change profile when placed in charger.
In the Change to profile drop-down list, select the profile to be used. By default,
only the profile Normal is selectable. If configured, additional profiles will be
visible, see
5.15.2 In Charger Action when in Call
The handset can be configured to end a call, or turn on the loudspeaker when it is placed in a
charger during a call. If the handset is removed from the charger during the call, it will not
return to previous settings.
1 Select Connections > In Charger
2 In the Call behaviour drop-down list, select one of the following:
• No action - no action will be performed when handset is placed in charger
• End - the handset will disconnect calls when placed in charger
Note: Some systems/PBXs require that the handset sends a DTMF tone in order to
end a call, See
configuration.
• Put on Loudspeaker - the handset will activate the loudspeaker mode when
placed in charger.
5.15.3 Clear Lists when inserted in Charger
The handset can be configured to clear lists when placed in a charger. The following
message and call lists will then be cleared:
• Inbox
• Unsent
• Sent
• Call list
• Missed calls
1.TIf the parameter "Possible to turn off sound" is set to "No", the handset will not be muted when placed in charger..
25 November 2011 / Ver. E
5.35.1 User Profiles on page 43.
5.11.1 Send DTMF Tone when Pressing On-Hook key
TD 92639EN
1
on page 25 for
27
