Configuration Manual
Ascom d62 DECT Handset
2

Getting started with Configuration of the d62 handset

It is possible to configure the d62 handset by inserting it into a desktop charger (DC4) or
rack charger (CR3). The charger is connected via USB or ethernet to the PDM Windows
Version or the IMS3.
In the case of IP-DECT, it is possible to configure the d62 over the air.
This chapter describes how to configure handsets in three different system setups:
• with PDM Windows Version
• with IMS3 via chargers
• with IMS3 over-the air
2.1

PDM Windows Version

The Windows Version is run on a PC. The handset is configured via PDM Windows Version as
follows:
• Connect a desktop charger (DC4) or a rack charger (CR3) via USB to the computer
running PDM.
• Start PDM.
• Place the handset in this charger which shall be connected to PDM. The handset can
either be turned off or turned on when placing it in the charger. A handset that is turned
off will start up automatically and the battery charging symbol will be displayed.
For instructions on how to use PDM Windows Version, see Installation and Operation Manual,
Portable Device Manager (PDM), Windows Version, TD 92325EN.
Figure 1. Configuration of handsets via PDM Windows Version
2.2

Device Manager in IMS3

The Device Manager in IMS3 runs on an ELISE3 module.
For instructions on how to use the IMS3, see Installation and Operation Manual, IMS3,
TD 92762EN.
25 November 2011 / Ver. E
Figure 1.
TD 92639EN
5
