Note The NPE-300 contains two banks of SDRAM. Both SDRAM banks are used for all
packet memory requirements; however, bank 0 is used exclusively for packet memory and
is set at a fixed configuration in the factory.
Bank 1 contains two user-configurable SDRAM slots, DIMM slot 2 and DIMM slot 3 (see
Figure 1-10). Both slots in bank 1 can be populated by DIMMs of different sizes; however,
the size of the DIMM in slot 2 must be greater than or equal to the size of the DIMM in
slot 3, and the size of the DIMM in slot 3 can be zero.
Table 1-7 lists the NPE-300 factory-installed SDRAM configurations and their product
numbers.
Table 1-7 NPE-300 SDRAM DIMM Configurations
Total
SDRAM SDRAM Bank 0
32 MB U45 (DIMM slot 2
only)
64 MB U45 and U44
or
U45
128 MB U45 and U44
or
U45
256 MB U45 and U44
1 There are two user-upgradable SDRAM slots in bank 1. (Bank 0 is used exclusively for packet
memory and is set at a fixed configuration in the factory.)
2 These products are also available as SDRAM upgrades. To order an upgrade, add an equal sign
(=) after the product number, for example, MEM-SD-NPE-128MB=.
1
Quantity
1-32-MB DIMM
2 32-MB DIMM
or
1 64-MB DIMM
2 64-MB DIMMs
or
1 128-MB DIMM
2 128-MB DIMMs
Cisco 7200 VXR Product Overview 1-25
Network Processing Engine
2
Product Number
MEM-SD-NPE-32MB
MEM-SD-NPE-32MB
MEM-SD-NPE-64MB
MEM-SD-NPE-64MB
MEM-SD-NPE-128MB
MEM-SD-NPE-128MB
