Rack-Mounting a Cisco 7200 VXR Router
Figure 3-4
Rack-Mounting the Chassis in a Telco-Type Rack with Installed
Cable-Management Brackets—Front Installation Shown
Cisco 7200
Series
Rack-mount
bracket
3-6
Cisco 7200 VXR Installation and Configuration Guide
ETHERNET 10BT
Cable-management bracket
TOKEN RING
ETHERNET-10BFL
FAST ETHERNET INPUT/OUTPUT CONTROLLER
