Figure 1-12
I/O Controller—Without Fast Ethernet Port
Temperature
sensor
Captive
installation
screw
PC Card slots
Boot ROM U20
Auxiliary
LED and
port
CPU reset
button
Cisco 7200 VXR Product Overview 1-29
Input/Output Controller
Midplane
connectors
Flash SIMM U99
NVRAM U41
Temperature
sensor
Console
port
