Input/Output Controller
Depending on whether the Fast Ethernet port is present, up to five LEDs on the
I/O controller faceplate indicate system status; two additional LEDs indicate the status of
the Flash Disks or Flash memory cards installed in either PC Card slot.
Figure 1-14 shows the LEDs on the I/O controller with the Fast Ethernet port that is
equipped with a single MII receptacle.
Note Although still supported by Cisco Systems, the I/O controller equipped with the
single MII receptacle is no longer an orderable product as of May 1998.
Figure 1-15 shows the LEDs on the I/O controller with the Fast Ethernet port that is
equipped with an MII receptacle and an RJ-45 receptacle. Figure 1-16 shows the LEDs on
the I/O controller without the Fast Ethernet port. Table 1-9 lists I/O controller LEDs and
their functions. To use the LEDs for troubleshooting the I/O controller, see the section
"Identifying Startup Problems" in the appendix "Troubleshooting the Installation."
A CPU reset button is located next to the IO power OK LED or the auxiliary port on the
I/O controller faceplate. The CPU reset button resets the entire system.
Caution To prevent system errors and problems, use the CPU reset button only at the
direction of your service representative.
Cisco 7200 VXR Product Overview 1-31
