Figure 1-8
NPE-200
System
controller
R5000
microprocessor
4-MB SRAM
U6, U10, U13,
U14, U28, U29,
U38, and U39
Captive
installation
screw
Temperature
Handle
sensor
Network Processing Engine
Midplane
connectors
Temperature
sensor
Boot ROM U92
DRAM SIMMs
U52
Bank 1
U42
U25
Bank 0
U11
Cisco 7200 VXR Product Overview 1-19
