Cisco 7200 VXR router User Manual page 31

Figure 1-10 NPE-300
SDRAM DIMMs
bank 1
Keying post
DIMM 3
U44
DIMM 2
U45
Captive
installation
screw
Table 1-2 lists the NPE-100, NPE-150, and NPE-200 network processing engine memory
components.
Table 1-2 Network Processing Engine Memory Specifications
Memory Type Size
DRAM 32 to 128 MB
Midplane
connectors
System controllers
Handle
RM7000
microprocessor
Quantity Description
2 to 4 16- or 32-MB SIMMs (based on
maximum DRAM required)
Network Processing Engine
SDRAM DIMMs
bank 0
Keying post
Boot ROM
U1
DIMM 0
U16
DIMM 1
U15
Location
Bank 0: U18 and U25 or U11
and U25
Bank 1: U4 and U12 or U42
and U52
Cisco 7200 VXR Product Overview 1-21
1
2
