Installing the Cable-Management Brackets

Installing the Cable-Management Brackets
To install the cable-management brackets on a Cisco 7200 VXR router, complete the
following steps:
Step 1
Step 2
Step 3
Step 4
This completes the steps for installing the cable-management brackets on a Cisco 7200
VXR router.
Securing the Port Adapter Cables
To secure port adapter interface cables to the cable-management brackets, complete the
following steps:
Note
port adapter interface cables to the brackets. We recommend that you use the tie wraps that
shipped with the cable-management brackets.You can use standard tie wraps; however, you
will have to cut and replace them with new tie wraps when you want to release or secure an
interface cable to a bracket.
Step 1
Step 2
3-16 Cisco 7200 VXR Installation and Configuration Guide
Locate the threaded holes in the front sides of the chassis.
Align the first cable-management bracket to the threaded holes in the right side
of the chassis. (See Figure 3-5.)
Thread two M4 x 8-mm Phillips flathead screws through the bracket and into the
chassis. Use a number 2 Phillips screwdriver to tighten the screws.
Repeat Step 1 through Step 3 to install the other cable-management bracket on
the left side of the chassis.
The eight removable tie wraps installed on the cable-management brackets secure
Select a tie wrap and release its locking mechanism.
Carefully lace the interface cables from a port adapter installed in the chassis
between the two ends of the unlocked tie wrap.
Be sure to leave a small service loop in the interface cable before securing
Note
it to the cable-management bracket.
