Figure 1-3
Cisco 7206VXR Router—Front View
Port adapter
Cisco 7200
Series VXR
lever
I/O controller
Note
across the port adapters, each port adapter slot must be filled with either a port adapter or a
blank port adapter.
The rear of the Cisco 7206VXR router provides access to the network processing engine
and up to two power supplies. (See Figure 1-4.)
Blank port adapter
PC Card slots
Optional Fast Ethernet port
(MII receptacle and RJ-45 receptacle)
In Figure 1-3, a blank port adapter is installed in slot 5. To ensure adequate airflow
Port adapters
ETHERNET 10BT
FAST ETHERNET INPUT/OUTPUT CONTROLLER
Auxiliary
Console
port
Cisco 7200 VXR Product Overview 1-9
Cisco 7206VXR Overview
TOKEN RING
ETHERNET-10BFL
port
