Configuring a Cisco 7200 VXR Router
Your router is now minimally configured and ready to use. You can use the setup command
if you want to modify the parameters after the initial configuration. To perform more
complex configurations, use the configure command.
For information on additional interface configuration and specific system configurations,
refer to the modular configuration and modular command reference publications in the
Cisco IOS software configuration documentation set that corresponds to the software
release installed on your Cisco hardware.
Performing a Basic Configuration Using Global Configuration
Mode
You can configure a Cisco 7200 VXR router manually if you prefer not to use the setup
facility or AutoInstall. Complete the following steps to configure the router manually:
Step 1
Step 2
Step 3
Step 4
4-16 Cisco 7200 VXR Installation and Configuration Guide
Connect a console terminal to the console port on the I/O controller.
When asked if you want to enter the initial dialog, answer no to go into the
normal operating mode of the router:
Would you like to enter the initial dialog? [yes]: no
After a few seconds the user EXEC prompt
to enter enable mode (configuration changes can only be made in enable mode):
Router> enable
The prompt changes to the privileged EXEC prompt:
Router#
Enter the config terminal command at the enable prompt to enter configuration
mode from the terminal:
Router# config terminal
Enter configuration commands, one per line.
Router(config)#
is displayed. Type enable
(Router>)
End with CNTL/Z.
