Field-Replaceable Units
Figure 1-5
NPE-100
System
controller
R4700
microprocessor
Captive
installation
screw
1-16
Cisco 7200 VXR Installation and Configuration Guide
Temperature
Handle
sensor
Midplane
connectors
Temperature
sensor
DRAM SIMMs
U12
Bank 1
U4
U25
Bank 0
U18
