CYBEX SOLUTION Q2-FIX User Manual page 11

w
u
y
i
w
CLICK!
CLICK!
v
x
• For adjustment pull handle (v), located on the bottom of the
seat.
• Pull the ISOFIX connectors (w) out as far as possible.
• Rotate the connectors 180° until they point towards the ISOFIX
guides (u).
!
WARNING! Please ensure that the two green safety
indicators (x) of the connectors are not visible. If necessary,
release the ISOFIX connectors by pushing and pulling back
the red release button (y). Repeat this procedure with the
other connector.
• Push both of the ISOFIX connectors (w) into the ISOFIX guides
(u) until you hear them click into the ISOFIX anchorage points
(i).
• Ensure that the child seat is connected safely by trying to pull
it out.
• The green safety indicators (x) must then be clearly visible on
both of the red release buttons (y).
• You can now adjust the position of the seat using the handle (v)
located on the bottom of the child seat
NOTE! For additional information please refer to the section
"PLACING THE SEAT IN THE CAR".
• You can now buckle up the child. Please refer to "FASTENING
THE CHILD`S SEATBELT".
11
