4. Secure the FileCruiser or to the rack.
The unit attaches to the rack posts using the included screws and flange nuts.
One screw each side, in the upper hole only.
Use the attaching screws and flange nuts that came with the FileCruiser.
Figure 6: Secure to rack
Screws and flange nuts
attach the FileCruiser to
the rack posts
Figure 7: System installed in rack
Vertical rack post
Handles mount outside
the rack post
Mounting rails mount
outside the rack post
