Promise Technology FileCruiser VA2600 Hardware Installation Manual page 8

Promise Technology
Figure 1: FileCruiser VA2600 front view
Drive carriers
A defective drive may be replaced without interruption of data availability to the host
computer. The self-contained hardware-based RAID logical drive provides maximum
performance in a compact external enclosure.
Figure 2: FileCruiser VA2600 rear view
PSU fans
Power inserts
Power and Status LEDs
See "Front Panel LEDs" on page 16
System fan
Ports and LED indicators on control panel
6
PCIe card access
(requires riser card)
