BUILT-IN REFRIGERATION
Opening Dimensions
FLUSH INSET INSTALLATION
665 mm
FLUSH
INSET
DEPTH
6 mm
2134 mm
FLUSH
INSET
HEIGHT
SIDE VIEW
*76 mm typical depth. Shaded areas will be visible and should be finished to match cabinetry.
NOTE: Shaded line represents profile of unit with 19 mm panel.
FLUSH INSET WIDTH
MODEL
ICBBI-36R, ICBBI-36F
ICBBI-30U
ICBBI-36U, ICBBI-36UFD, ICBBI-36S
ICBBI-42S, ICBBI-42SD
ICBBI-48S, ICBBI-48SID, ICBBI-48SD
56
mm
FINISHED
CLEATS*
TOP VIEW
32 mm
W
FLUSH INSET WIDTH
FRONT VIEW
W
965 mm
813 mm
965 mm
1118 mm
1270 mm
32
mm
102 mm
76
56
mm*
mm
TYPICAL
Dimensions assume a 19 mm panel thickness.
If a 2108 mm grille height is specified, the flush inset height
must be decreased by 22 mm. If a 2235 mm grille height is
specified, the flush inset height must be increased by 102
mm.
If two units are installed side by side, refer to page 11 for
dual flush inset installations.
|
