WINE STORAGE
Opening Dimensions
MODEL ICBWS-30 FLUSH INSET INSTALLATION
665 mm
FLUSH
INSET
56
DEPTH
mm
6 mm
2134 mm
FLUSH
INSET
HEIGHT
SIDE VIEW
*76 mm typical depth. Shaded areas will be visible and should be finished to match cabinetry.
NOTE: Shaded line represents profile of unit with 19 mm panel.
FLUSH INSET WIDTH
MODEL
ICBWS-30
FINISHED
CLEATS*
TOP VIEW
32 mm
W
FLUSH INSET WIDTH
FRONT VIEW
Dimensions assume a 19 mm panel thickness.
W
If a 2108 mm grille height is specified, the flush inset height
813 mm
must be decreased by 22 mm. If a 2235 mm grille height is
specified, the flush inset height must be increased by 102
mm.
If two units are installed side by side, refer to page 53 for
dual flush inset installations.
32
mm
102 mm
76 56
mm
mm*
TYPICAL
|
