BUILT-IN REFRIGERATION
Dual Installation
DUAL WIDE GRILLE
A dual wide grille spans the entire width of both units in a
dual installation and is a part of a dual installation kit.
For overlay and flush inset panel dimensions for the dual
wide grille, refer to the charts below. Dimensions listed are
for a standard 2134 mm finished height.
DUAL WIDE GRILLE—OVERLAY
TWO 762 mm MODELS
Overlay Panel
Spacer Panel
Backer Panel
762 mm MODEL AND
914 mm MODEL
Overlay Panel
Spacer Panel
Backer Panel
TWO 914 mm MODELS
Overlay Panel
Spacer Panel
Backer Panel
W H
1530 mm 235 mm
1508 mm 211 mm
1524 mm 227 mm
W H
1683 mm 235 mm
1661 mm 211 mm
1676 mm 227 mm
W H
1835 mm 235 mm
1813 mm 211 mm
1829 mm 227 mm
DUAL WIDE GRILLE—FLUSH INSET
TWO 762 mm MODELS
Flush Inset Panel
Spacer Panel
Backer Panel
762 mm MODEL AND
914 mm MODEL
Flush Inset Panel
Spacer Panel
Backer Panel
TWO 914 mm MODELS
Flush Inset Panel
Spacer Panel
Backer Panel
W H
1556 mm 235 mm
1508 mm 211 mm
1524 mm 227 mm
W H
1708 mm 235 mm
1661 mm 211 mm
1676 mm 227 mm
W H
1861 mm 235 mm
1813 mm 211 mm
1829 mm 227 mm
|
