BUILT-IN REFRIGERATION
Dual Installation
If two units are installed side by side, a dual installation kit
may be required. Installations without a custom filler strip
require a dual installation kit. If a dual installation kit is not
specified, a 51 mm filler strip is recommended between
units. A custom filler strip is required when installing two
French door or side-by-side models. Dual installations
without a filler strip can only be accomplished using two
units with opposite hinges. Refer to the illustrations below.
Dual installation kits are available through an authorized
Sub-Zero dealer. For questions regarding the installation,
contact your authorized Sub-Zero dealer.
WITHOUT FILLER STRIP
Opposite hinges.
|
20 English
FILLER STRIP
Same side hinges.
For dual standard installations, panel dimensions are the
same as for single installations. Refer to the charts on pages
15–16. Panel dimensions and offsets for dual flush inset
installations are listed on the following pages.
