Chapter 3
[1]
3) Open the operation panel. As you disengage the claw [1], remove the right
cover [2].

3.6.1.4 Removing the Left Cover

/ / FAX-L380S
1) Open the front cover [1], and remove the two screws [2] on the front side.
[2]
2) Remove the two screws [1] on the back side.
3) Open the operation panel. As you disengage the claw [1], remove the left
cover [2].
3-52
F-3-365
[1]
[2]
F-3-366
[1]
F-3-367
[1]
F-3-368
[2]

3.6.1.5 Removing the Left Cover

/ / FAX-L390
1) Open the front cover [1], and remove the two screws [2] on the front side.
[2]
0011-4841
2) Remove the two screws [1] on the back side.
3) Open the operation panel. As you disengage the claw [1], remove the left
cover [2].
[2]

3.6.1.6 Removing the Cassette Rear Cover

/ / FAX-L390
1) Remove the two screws [1] to remove the cassette rear cover [2].
[1]
F-3-369
[1]
F-3-370
F-3-371
[1]
F-3-372
0011-6359
[1]
0011-6360
