Parts list

When ordering spare parts please quote the order
code number to your installer/dealer.
Item/description
1 Base
2 Mounting bracket ext
3 Shaft 271555
4 Quad counter
5 Partition moulded
6. Helical gear 5015
7. Ball bearing 6004.2RS
8. Key 8750
9. Compres. spring 91501
10. Shaft bearing housing
11. Gear 14T
12. Key 528
13. External circlip D1400 0160
14. Quad-gray 3.02 board
15. Plate timing
16. Limits wheel
17. Limits shaft 663
18. Helical gear 40075
19. E circlip D1500 0040
20. Taptite screw 'P' M3 x 8
21. Drive assy DCM-11
22. Worm 2315
23. Sel-lok spring pin ACP M3 x 20
24. Door
25. Locks-key
26. Top and bottom lock cap
27. Microswitch ABS 111454
28. M/SW harness ESV24/240
29. Hinge pin
30. Rod disengagement
31. Transformer 150VA-05546 TDB-150-08 05546
32. Washer rubber 75 x 8 x 1
33. Washer cap 75 x 6.2 x 10.2H x 1.5T
34. Hex head screw M6 x 75
35. Spring washer I.D 6
37. PCB support
38M. Control board CB-11 V-1.02 master 01060
38S. Control board CB-11 V-1.02 slave
39M. PCB cover assy ESV24/240 master
39S. PCB cover assy ESV24/240 slave
38 Easy Slider - Sliding Gate Opener
order code 40. Power cord 1.5m W2PIN + 1 ring
02400 41. Terminal block 500/02DS 2 POS
02502 45. Cover slider
04504 46. Top cover
47. Slider label ESV24
02450
02440 48. Taptite screw 'P' M4 x 10
04050 49. Antenna 433Mhz with 3.0m Coax. cable 01971
03900 50. Q-G 301 harness assy
04404 51. Nylon cable gland PGB7-07B
52. Plug - dia 21 hole
02872
02410 53. Plug - 8 x 32
15080 54. Earth label
15180 55. Cap head screw M8 x 25
10780 56. Button head screw S.S M6 x 16
57. Pan head screw ZnCROM M5 x 16
01698
02702 58. Button head screw ZnCROM M4 x 10 10027
16358 59. Pan head screw w/washer M4 x 10
04030 60. Pan head screw w/washer M4 x 8
04040 61. Pan head screw M3 x 14
62. Pan head screw M2.5 x 10
10830
10560 63. Spring washer I.D 8
00300 64. Cable tie 4" GT-100M
04934 65. Spring washer I.D 5
02576 66. Internal tooth lock washer I.D 3
67. Taptite screw 'P' M4 x 12
02420
04620 68. Nylon gland M16-07B
15220 69. Securacode PTX-4 and wallswitch pack 01220
09261 70. Transmitter grey buttons PTX-4
12240 71. Transmitter red buttons PTX-4
72. PTX holder
02560
02565 73. Alkaline battery A23 12V
74. Plastic wall plug
04887
11165
10261
10960
02430
01062
02490
02491
Owner Installation Instructions
14150
05421
02460
02470
13572
10570
01795
05622
11881
11885
13704
10070
10023
10474
10340
10320
10360
10375
10950
14160
10970
11150
10569
05621
01210
01211
05196
13030
01479
