Specifications
Technical Specifications
Protection rating:
Input voltage:
Transformer primary voltage:
Secondary voltage:
Controller voltage:
Motor type:
Motor voltage:
Maximum pulling force:
Maximum gate opening:
1,2
Opener maximum
Opening/closing run time:
Receiver type:
Receiver code storage capacity:
Transmitter frequency:
Coding type:
No. of code combinations:
Code generation:
Transmitter battery:
NOTE:
1. The maximum opening that the EasySlider can be installed on is 5700mm wide and 250kg. The gate must
be well balanced. A person should be able to move the gate manually with very little effort (15kg force max.)
in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind
puts extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection
system intermittently.
NOTE: Specifications are subject to change without notice.
IP33
230V - 240V AC 50Hz
230V/240VAC
24V AC 150 VA
24V DC
Permanent Magnet Direct Current
24V DC
200N
Width: 5700mm
Height: 250kg
30 seconds
UHF 433.92 MHz am Receiver
30 x 4 Button Transmitter Codes
433.92 MHz
Hopping Code
Over 4.29 billion random codes
Non-linear encryption algorithm
A23 Alkaline 12V
