Memory

Supported DIMM configurations

NOTE: Mirroring and DIMM sparing are not supported.
Platform
SFF
Tower

BIOS errors and warnings

The BIOS generates warnings/errors on invalid memory configurations:
If the BIOS can find a valid memory configuration by disabling plugged-in memory, it does so and
●
reports a warning during POST. the workstation can still be started. The warning will indicate the
location of the failed DIMM on the system board.
● If there is no way for the BIOS to obtain a valid memory configuration by disabling plugged-in memory,
the BIOS halts with a diagnostics 2006 code for memory error (five beeps and blinks).

DIMM installation guidelines

● Install only HP-approved DDR3 DIMMs
CAUTION:
Because third-party DIMMs might not be electrically or thermally compatible, they are not supported by
HP.
● Install only HP-approved DDR3 DIMMs. See
compatible with the workstation.
● Do not intermix DIMMs of different technologies. ECC Unbuffered DIMMs (UDIMMs), Registered DIMMs
(RDIMMs), and Load Reduced DIMMs (LRDIMMs) are supported on your workstations.
configurations on page 53
CAUTION: DIMMs and their sockets are keyed for proper installation. To prevent socket or DIMM damage,
align these guides properly when installing DIMMs.
● Four DIMM slots
● Unbuffered ECC/nECC DIMMS only
● Maximum capacity: 64 GB
● Four DIMM slots
Unbuffered ECC/nECC DIMMS only
●
● Maximum capacity: 64 GB
HP ships only DIMMs that are electrically and thermally compatible with this workstation.
specifies which technologies are supported on each platform.
Configuration
http://www.hp.com/go/quickspecs
Component replacement guidelines
to find DIMMs that are
Supported DIMM
53
