Workstation specifications

Processor
technology
Power supply
Memory
technology
Graphics cards
I/O technology
Intel Series C236 chipset:
● Support for the Intel® Xeon® Processor E3 v5 Family, sixth-generation Intel Core™ processors up to 95
W, or Intel Pentium® processors
● Integrated 2-channel memory controller
● Microarchitecture improvements
● Integrated graphics (some models)
Advanced Vector Extensions (AVX) to increase floating point performance
●
● Intel DMI3 interface connecting the processor to the I/O controller
● 240 W, 92% efficient, compatible with ENERGY STAR® Version 6.1 requirements
● 200 W, 85% efficient, compatible with ENERGY STAR Version 6.1 requirements
● Supports European Union ERP Lot 6 tier 2 power limit of less than 0.5W in off mode
● Dual in-line memory modules (DIMMs) based on DDR4 2133 MHz technology
● Supports error checking and correcting (ECC) and non-ECC DIMMs
● Two direct-attach memory channels enable low-latency access and fast data transfer for improved
performance
● Up to 64 GB system memory (16 GB DIMMs)
● 2133 MHz 4, 8, 16 GB ECC unbuffered DIMM
● 2133 MHz 4, 8, 16 GB non ECC unbuffered DIMM
Supports:
● Up to PCIe Gen 3 bus speeds.
● PCIe x16 cards are supported in both x16 mechanical slots. Multiple graphics cards are supported,
provided their total power consumption is less than 45W.
● Up to three displays with integrated Intel HD graphics (depending on processor type)
● The total number of displays supported depends on the number of graphics cards present, and the
number of outputs on each card.
● Windows 10 supports display output from both integrated graphics capable processors and discrete
graphics cards. This feature is enabled by default, and can be changed through the Computer Setup
(F10) Utility.
NOTE: Most supported Intel Core processors provide Intel HD Graphics 510/530; Intel Xeon processors with
model designations that end in "___5" provide Intel HD Graphics P530.
NOTE: To drive more than three displays, use Computer Setup (F10) Utility to intermix integrated Intel HD
graphics and discrete graphics cards (with four or more displays, HP recommends using only discrete
graphics cards).
● RAID configurations for SATA RAID levels 0, 1
● Two external and one internal USB 2.0 ports (includes front charging port)
● Eight external USB 3.0 ports and one internal USB 3.0 port
● Three DisplayPort 1.2 connectors
Serial header that can be used with an optional PCI bulkhead connector
●
Native M.2 connector with PCIe x4 interface
●
SFF
HP Z240 SFF Workstation components 7
