HP Z240 SFF Workstation components

This section describes the HP Z240 Small Form Factor (SFF) Workstation components.
For complete and current information on supported accessories and components for the computer, see
http://partsurfer.hp.com.

HP Z240 SFF Workstation front panel

1
2
3
4
5
2
Chapter 1 Hardware overview
Power button
HDD LED
Optional optical disc drive (not shown)
Optional hard disk drive (not shown)
Optional media card reader (shown)
6
USB 2.0 port, charging (1, black)
7
USB 2.0 port (1, black)
8
USB 3.0 ports (2) (blue)
Microphone or headphones connector
9
(software selectable, default mode is
microphone)
10
Headphones connector
