C
System board designators

SFF workstation system board designators

Designator
Silk screen
E15
E15 BBR
E49
E49 PSWD
J9
RJ45/USB
J10
J10 USB2/USB3
J31
J31 X1PCIEXP1
J32
J32 X1PCIEXP2
J41
J41 X16PCIEXP
J42
J42 X4PCIEXP
J63
J63 DISPLAY PORT
J64
J64 DISPLAY PORT
J68
PS2
J78
IN/OUT
J86
M.2 SSD
JZ87/88
JZ87/88
SW50
SW50 CMOS
P1
PWR
P2
PWRCMD
P3
PWRCPU
P5
P5 PB/LED
P6
SPKR
P8
CPU FAN
P23
FRONT AUD
P24
FRONT USB
P52
COMB
P124
HLCK
P125
HSENSE
P150
Media
P152
SD RDR
92

Appendix C System board designators

Component/Description
Crisis recovery header/jumper
Clear password header/jumper
LAN/DUAL USB 3.0
Quad USB 3.0
PCIe3 x1 slot (black)
PCIe3 x1 slot (black)
PCIe3 x16 slot (black)
PCIe3 x16(4) slot (black)
Dual-Mode DisplayPort connector
DisplayPort connector
Mouse connector stacked over keyboard connector
Audio line in stacked over audio line out
M.2 connector
Slot1/4 PCIe x16 retention clip
Clear CMOS switch/push button
Power supply, 6-pin (white)
Power command, 6-pin (white)
Power supply, 4-pin (white)
Front power button/LED (black)
Internal speaker (white)
CPU fan header
Front audio (blue)
Front I/O USB (yellow)
Serial port
Hood lock solenoid (black)
Hood sensor
int-Media (6-pin)
USB 3.0 Media card reader
