SHOULDER PADS (if fitted)
The shoulder pad is designed to add extra
comfort for baby or child.
STANDARD
Step 1: Separate press-studs and remove the
shoulder pads from harness
Step 2: To attach shoulder pads, ensure press studs
face away from the child and re-attach.
DELUXE
Step 1: Turn the restraint so that the back of the seat
is facing you.
Step 2: Remove each shoulder harness through
the gates in the spreader plate (refer Figure
1 & 2).
Step 3: Pull the shoulder harness straps through the
shoulder slot holes in the seat body and
cover. They are now loose in the front of the
seat (refer Figure 2).
Step 4: To attach shoulder pads, slide the shoulder
pad over the harness straps (refer Figure 3).
Step 5: Rethread harness straps as per Steps 1 to 3
above.
The child restraint with shoulder pads is
ready to use.
DELUXE
ACCESSORIES
STANDARD
HARNESS
STRAPS
METAL
SPREADER
PLATE
SPREADER
PLATE
Figure 1
PULL
Figure 2
Figure 3
