Step 7:

Push down on the base of the restraint (with knee or

hand) whilst pulling the sash section of the vehicle

belt firmly up in direction of the yellow arrow in Figure

5. (This will tighten the lap belt across the seat base).

Whilst continuing to pull the sash section up, attach

the Safe Grip red belt clamp on the sash section

ONLY as close as possible above the buckle tongue

assembly. (Refer to Figure 6 and Instruction for

installing the Safe Grip red clamp below)

Step 8:

Ensure the excess slack in the sash belt, is fed back

towards the seat belt.

SAFE GRIP BELT CLAMP

The Safe Grip (red belt clamp) locks the lap

belt to ensure a firm installation, and avoids

slack in the lap belt.

To install the Safe Grip (red belt clamp), open it

and clamp the "sash section"ONLY of the vehicle

seat belt by closing the barrel section of the red

belt clamp in the direction of arrow 1 in Figure 6

and then locking with the toggle section by

pushing in the direction of arrow 2 in Figure 6

when the Safe Grip (red belt clamp) is secured in

place, the lap section is now tightly holding your

child restraint in place, independent of the sash

section. The Safe Grip (red belt clamp) must be

removed when the child restraint is not installed

to allow other users to use the seat belt as a

lap/sash seat belt. Always keep the Safe Grip

(red belt clamp) in pocket provided when not in use.

ADJUSTING RECLINE ANGLE

NOTE: To adjust the recline angle of the child seat

refer to "Converting to Child Seat" on page 23.

INSTALLATION
