Cs4010/Cs4410 Child Restraint (Itemised List) - Infasecure CS4010 Instructions Manual

8
15
11
16
1.
UPPER ANCHORAGE STRAP ADJUSTER
2.
UPPER ANCHORAGE STRAP
3.
ATTACHMENT CLIP
4.
ANCHOR FITTING + ATTACHMENT HARDWARE
5. SAFE GRIP RED BELT CLAMP (supplied in pocket)
6.
VEHICLE SEAT BELT
7.
"FORWARD-FACING SEAT BELT PATH" MARKER
(EACH SIDE OF RESTRAINT - COLOURED YELLOW)
8.
UPPER ANCHORAGE STRAP GUIDE
9.
COMFORT COVER
A - SEAT COVER
For a vehicle without a fixed parcel shelf an extension strap(s) may be needed.
If so ring (02) 4728 8080 for nearest supply location. (Refer page 31)
Seat belt extenders should not be used if the seat belt is not long enough to secure the child
restraint.
CS4010/CS4410
FORWARD FACING
Shoulder height markers may
be hidden under a pillow in
the lowest position
5
!
IMPORTANT
6
10
9 A
12
VIEW A
13
14
10.
SHOULDER HEIGHT MARKER
11.
HARNESS SHOULDER STRAPS
12.
BUCKLE ASSEMBLY
13.
HARNESS ADJUSTER
14.
HARNESS ADJUSTMENT STRAP
15.
PILLOW (if supplied)
16.
PADDED INSERT (if supplied)
NOTE: Padded inserts can vary according to model.
For detailed description and method of attachment
for padded accessories refer to Accessories on page 31.
20
Front
of Car
7
VIEW A
