CS5610
Expanding Booster Seat
To be used with a lap-sash
seatbelt by children whose
shoulders are above the lower
shoulder height marker with the
head restraint in lowest position
(approximately 4 years of age)
until the child's shoulders
reach the upper shoulder
height marker with the
head restraint in highest
position (approximately
6 to 8 years of age)
MODELS
*All references to age are to an average proportioned child to age.
1754:2010
Licence No. 25324

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS5610 and is the answer not in the manual?

Questions and answers

Related Manuals for Infasecure CS5610

Summary of Contents for Infasecure CS5610

  • Page 1 CS5610 MODELS Expanding Booster Seat To be used with a lap-sash seatbelt by children whose shoulders are above the lower shoulder height marker with the head restraint in lowest position (approximately 4 years of age) until the child’s shoulders reach the upper shoulder...

  • Page 2: Suitability Of The Child Restraint

    Expanding Booster Seat SUITABILITY OF THE CHILD RESTRAINT The CS5610 Expanding Booster Seat is suitable for toddlers to older children as a booster seat. FORWARD FACING BOOSTER SEAT TO BE USED WITH A LAP-SASH SEATBELT BY CHILDREN WHOSE SHOULDERS ARE ABOVE THE LOWER SHOULDER HEIGHT MARKER WITH THE HEAD RESTRAINT IN LOWEST POSITION (APPROXIMATELY 4 YEARS OF AGE) UNTIL THE CHILD’S SHOULDERS REACH THE UPPER...
  • Page 3 - For cars not fitted with anchorage points Page 4-4 BOOSTER SEAT - Shoulder Height Marker Page 5-6 - Carseat Table Page 7 - CS5610 Child Restraints (Itemised list) Page 8 SET UP - Adjusting the headrest Page 9 - Adjusting the side wings Page 9...

  • Page 4: Anchorage Fittings

    WARNING If no anchorage points can be found refer to Upper anchorage strap and attachment clip the Vehicle manufacturer, or an authorised child must always be used restraint fitting station for the best location of an anchorage point. Upper anchorage strap and attachment clip must only be attached to the correct anchor fitting Always ensure that the upper attachment clip...

  • Page 5: Anchorage Fittings

    FOR CARS NOT FITTED WITH A CHILD RESTRAINT ANCHORAGE POINT UPPER ANCHORAGE FITTINGS FOR SEDANS ONLY Attachment Bolt WARNING SIDE VIEW...

  • Page 6: Shoulder Height Marker

    SHOULDER HEIGHT MARKER SMALLER CHILD LOWER LABEL Smaller Child from approximately 4 years of age Do not use this booster seat if the child’s shoulders are below the lower shoulder height marker, (Lower label) when the headrest is in the lowest position SHOULDERS BELOW THIS LINE WHEN HEADREST AT HIGHEST POSITION SHOULDERS ABOVE THIS LINE WHEN...

  • Page 7: Shoulder Height Marker

    SHOULDER HEIGHT MARKER TALLER CHILD UPPER LABEL Taller Child up to approximated 8 years of age Continue to use this booster seat until the child’s shoulders reach the upper shoulder height marker, (Upper Label) when the headrest is in the highest position SHOULDERS BELOW THIS LINE WHEN UPPER LABEL...
  • Page 8 CARSEAT TABLE Front RESTRAINT GUIDE of Car MODE BIRTH REARWARD-FACING RESTRAINT (TYPE A1) 0 to 6 (months) BIRTH TO APPROX 6 MONTHS CONVERTIBLE REARWARD/ Approx 0 to 4 years FORWARD-FACING RESTRAINT (TYPE A/B) BIRTH TO 4 YEARS FORWARD-FACING RESTRAINT (TYPE B) Approx 6 months to 4 years APPROX 6 MONTHS TO 4 YEARS...
  • Page 9 MODEL CS5610 9 & 13 9 & 13 “BOOSTER SEATBELT PATH” MARKER UPPER ANCHORAGE STRAP ADJUSTER (EACH SIDE OF RESTRAINT - COLOURED RED) UPPER ANCHORAGE STRAP SLIDE-OUT CUP HOLDER (EACH SIDE OF RESTRAINT) ATTACHMENT CLIP COMFORT COVER ANCHOR FITTING + ATTACHMENT HARDWARE...
  • Page 10 IMPORTANT Refer to shoulder height marker (As shown on pages 5 and 6) Pull to tighten and remove all the ALWAYS ATTACH slack, from the upper anchorage ATTACHMENT CLIP WARNING strap. Do not overtighten as this AND REMOVE could cause the restraint to lift off ALL SLACK.

  • Page 11: Using Lap-Sash Seat Belt

    USING LAP-SASH SEAT BELT “INSTALLING IN VEHICLE” (refer page 9) the backrest adjust the headrest described in setup to best suit your child (refer page 9) Position the lap section of the vehicle seat across the child’s lap then insert the buckle tongue in the belt buckle (A).

  • Page 12: Using Lap-Sash Seat Belt

    USING LAP-SASH SEAT BELT IMPORTANT ALWAYS USE THIS SASH GUIDE SAFETY WARNING WARNING A sash belt under the arm or behind the back is dangerous To release your child from the restraint simply press the belt buckle and carefully remove your child from the seat.
  • Page 13 The CS5610 Booster Seat cover has been manufactured to meet the Australian Standards requirements for flammability and toxicity to ensure your childs safety. The cover has also been designed to provide your child with comfort and support. VERY IMPORTANT From the rear of the restraint disconnect...
  • Page 14 IMPORTANT Use only mild soap and water to clean all parts of the CS5610 Booster Seat. Do not use chemicals or cleaning agents Cold water only to be used and to be rinsed well Do not dry clean or tumble dry Do not bleach.
  • Page 15 CS5310, CS5410, CS5610 The serious risk of misuse of a child harness when used with a booster seat is causing a lowering of the safety of the child. This has been identified during a program jointly carried out by the Prince of Wales Medical Research Institute and NSW Centre for Road Safety, titled ‘...
  • Page 16 INFA-SECURÉ PTY LTD ABN: 52 149 173 660 Head Office and Registered Address 110-114 Old Bathurst Rd, Emu Plains, NSW 2750 P.O. Box 487, Emu Plains, NSW 2750 Phone No: 02 4728 8080 Fax: 02 4728 8040 Customer Service Phone No: 02 4728 8090 www.infa-secure.com.au ISSUE: B_1...
