Use; Using Inbuilt Harness; Release Child - Infasecure CS4010 Instructions Manual

Step 1: Ensure the restraint has been installed and set up as
per "Set Up" and "Installation" (Refer page 23 & 24).
Step 2: Lengthen the harness in excess of what is needed
before placing the child in the car seat. To lengthen
the harness, push the harness adjuster (G) that is
located at the front of the seat (see Figure 2) whilst
grasping both shoulder harness straps and pulling
out till lengthened to the desired amount. Ensure
shoulder straps are pulled equally on each side.
Step 3: Place child in car seat with legs either side of the
crotch strap, place harness over the shoulders and
hips and engage the two buckle tongues (CLICK) into
buckle. Check it is properly engaged. Ensure child is
placed centrally in the seat.
Step 4: Pull harness adjuster strap (H) to take the slack out of
the shoulder straps, until it is a firm but comfortable
fit. Ensure buckle is adjusted centrally in relation to
the child. Adjust if necessary (see Figure 2).
!
DO NOT LEAVE CHILDREN UNATTENDED
IN THE CAR.
Fit the harness firmly to the child.
A LOOSE RESTRAINT OR HARNESS
IS DANGEROUS.
To release your child from the restraint simply press
Step 1:
the harness buckle and carefully remove your child
from the seat.

USING INBUILT HARNESS

WARNING
TO RELEASE CHILD

USE

PULL TO
LENGTHEN
28
PULL TO
LENGTHEN
PRESS(G)
Figure 1
PULL TO
TIGHTEN(H)
Figure 2
Figure 3
