HARNESS BUCKLE

If sticky liquids such as baby formula, fruit juice, etc.
get inside your Harness Buckle, it may become sluggish.
An indication of a sluggish Harness Buckle is that you
cannot hear a "CLICK" when engaging the Harness
Tongues. To restore the Harness Buckle to good working
order it needs to be cleaned as follows:
From the underside of the restraint pull each crotch 3-bar
Step 1:
slide then turn 3-bar slide and push through each slot to
remove the Harness Buckle from the restraint (refer Figure 1).
Place the Harness Buckle under warm (max. 40 degrees
Step 2:
Celsius) running water as shown below. Let the water run
through the mouth of the buckle for five minutes. Do not
immerse the harness in water (refer Figure 2).
Engage and disengage the Harness Tongues and Buckles
Step 3:
several times until a strong audible "CLICK" is heard
when inserting the last tongue (refer Figure 3).
Step 4: If you still cannot hear a strong audible click after
engaging the Harness Tongues and Buckle, then repeat
cleaning several times. If the Harness Buckle cannot be
returned to its original working condition then contact
InfaSecure Customer Service.
Step 5: Refit the harness buckle to the restraint with the red
button facing out and feeding each 3-bar slide through
appropriate slot.
CARE OF RESTRAINT
CLEANING
Figure 3
31
Figure 1
Figure 2
"CLICK"
