Infasecure II Series Instruction Manual

Booster seat forward facing child car seat
Hide thumbs
Table of Contents

Advertisement

Quick Links

Booster Seat
F O R WA R D FA C I N G C H I L D C A R S E AT
MODELS: CS5413 SERIES II
(Forward Facing) Suitable for children from approximately 4 years to 8 years* of age.
Instruction Manual
IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED
ON THE CHILD RESTRAINT
*All references to age are approximates only and reference to children of average proportions.
Children vary in shapes and sizes. The photo displayed is indicative of the type of restraint and may
vary slightly depending on the model.
FORWARD FACING
4 8
TO
YEARS
YEARS
LIFETIME
WARRANTY
SEE INSIDE FOR MORE DETAILS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the II Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infasecure II Series

Summary of Contents for Infasecure II Series

  • Page 1 YEARS YEARS Booster Seat LIFETIME F O R WA R D FA C I N G C H I L D C A R S E AT WARRANTY MODELS: CS5413 SERIES II SEE INSIDE FOR MORE DETAILS FORWARD FACING (Forward Facing) Suitable for children from approximately 4 years to 8 years* of age. Instruction Manual IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT...

  • Page 2: Table Of Contents

    Please read carefully the whole of the instructions for installation and, in the event of doubt about the method of installation, to consult InfaSecure or agent, or a child restraint fitter, or in New Zealand, to consult the agent for the vehicle.

  • Page 3: Information

    InfaSecure recommended parts and accessories. Family Bussiness InfaSecure is an Australian owned and operated family business, AUSTRALIAN which can trace it's roots back over 60 years, becoming the single largest Australian owned and operated child restraint DESIGNED &...

  • Page 4: Warnings

    Warnings WARNINGS • Use the restraint exactly as shown in the instructions. • Supervision of children is needed because they may be able to undo buckles. • DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR. • Do not alter or modify this restraint. •...
  • Page 5 Warnings WARNINGS • THIS RESTRAINT IS NOT SUITABLE FOR USE WHERE THE TOP TETHER STRAP MAY FALL INTO A SPLIT IN THE SEAT BACK OR OFF THE SIDE OF THE SEAT. • THIS RESTRAINT MUST BE ATTACHED TO A CHILD RESTRAINT UPPER ANCHORAGE POINT IN THE CAR.

  • Page 6: Restraint Guide

    Research has shown that the likelihood of an accessory child safety harness being used incorrectly is very high and the risk of injuries when incorrectly used is much higher compared to a lap-sash seat belt. InfaSecure recommend that an accessory child safety harness should only be used if a lap-only seat belt is all that is available.

  • Page 7: Booster Seat

    Booster Car Seat Booster Seat (Forward Facing) THE SUITABILITY OF THE CHILD RESTRAINT TO GROUPS OF CHILDREN TYPE E To be used with a lap-sash seatbelt by a child whose shoulders are above the lower shoulder height marker (approximately 4 years of age) until the child’s shoulders reach the upper shoulder height marker (approximately 6 to 8 years of age).

  • Page 8: Shoulder Height Marker

    Booster Car Seat Shoulder Height Markers Smaller Child Shoulder height markers are provided on this restraint for a visual indication that the child is safe to travel in this restraint. Front of Car LOWER LABEL Smaller Child from approximately 4 years of age Do not use this booster seat if the child’s shoulders are below the lower shoulder height marker, (Lower label) SHOULDERS BELOW THIS LINE WHEN...
  • Page 9 Booster Car Seat Shoulder Height Markers Taller Child Shoulder height markers are provided on this restraint for a visual indication that the child is safe to travel in this restraint. Front of Car UPPER LABEL Taller Child up to approximated 8 years of age Continue to use this booster seat until the child’s shoulders reach the upper shoulder height marker, (Upper Label).

  • Page 10: Cs5413 Child Restraints (Itemised List)

    Booster Car Seat Model CS5413 1. Adjustable Headrest 6. Comfort Cover • Headrest 2. Shoulder Height Markers • Backrest 3. SAFE GRIP Red Belt Clamp (if supplied) • Seat Base 4. Vehicle Seat Belt 7. Top Tether Assembly • Tether Strap 5.

  • Page 11: Next Restraint

    Booster Car Seat Next Restraint Next Type of Restraint Refer to the ‘RESTRAINT GUIDE’ for the selection for the most appropriate next restraint (refer Page 5). When the child has outgrown the booster seat, then you can use either of the following;...

  • Page 12: Set Up

    Booster Car Seat Set Up Adjusting the Headrest The headrest can be adjusted to different heights, to best suit your child’s shoulder height. This can be done with the child in the seat. Grab the headrest, push or pull to move the headrest Step 1: either up or down.
  • Page 13 Booster Car Seat Installation Installing in Vehicle Pull to tighten and remove all the slack, from the Step 4: top tether strap (refer to Figure 3). PULL TO Do not overtighten as this could cause the ATTACH TIGHTEN restraint to lift off the vehicle seat. Roll up the excess webbing from top tether Step 5: strap and store in the pocket provided (refer...

  • Page 14: Use

    Booster Car Seat Using lap-sash seat belt Ensure the restraint has been installed as per “INSTALLING IN VEHICLE” (refer Figure 1) Sit your child in the restraint with their back against the backrest adjust the headrest as described in setup to best suit your child (refer Figure 2).
  • Page 15 • ALWAYS USE THE SASH GUIDE SLACK FROM SEATBELT Safe Grip (if supplied) *Can be purchased separately visit http://store.infasecure.com.au/ SAFE GRIP BELT CLAMP It is important that the lap belt must be firmly across the thighs. The Safe Grip locks the lap belt to...
  • Page 16 Booster Car Seat Using lap-sash seat belt Sash Guide Check the position of the headrest and adjust if needed (refer Page 9). Thread the sash belt through the sash guide on the bottom of the headrest. WARNING • DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR •...

  • Page 17: To Release Child

    Booster Car Seat To release child To release your child from the restraint simply press the belt buckle and carefully remove your child from the seat. It is not necessary to release the red belt clamp, to remove your child When the restraint is not in use, the seat belt should be fastened around it and engaged.

  • Page 18: Care Of Restraint

    1. Headrest Cover 2. Backrest Cover 3. Seatbase Cover VERY IMPORTANT Only replace the cover with a InfaSecure supplied replacement cover with identical shoulder height markers or a replacement cover meeting AS/NZS 8005. Care and Maintenance Regular care of the restraint will ensure safety of your child.

  • Page 19: Cleaning

    (B) Check the upper anchorage attachment clip to ensure plastic retainer clip is still present. Extension Straps If required contact infasecure for nearest supply location. Extension straps may be required in vehicle without a fixed parcel shelf (not included in this package)

  • Page 20: Accessories

    Accessories Follow the instructions covering the use of accessories provided with this child restraint or spare parts provided by InfaSecure for this restraint. IMPORTANT Use of unauthorised aftermarket accessories (i.e items not provided in this box with the child restraint), can reduce the safety provided by the child restraint and may cause injury or death.

  • Page 21: Anchorage Fittings

    ANCHORAGE POINTS. REFER TO A CHILD restraint) RESTRAINT FITTING STATION IF NO CAR If so ring InfaSecure on (Aust) (02) 4728 8090 for ANCHORAGE POINTS ARE IN THE MOTOR CAR. nearest supply location. • THIS RESTRAINT IS NOT SUITABLE FOR...
  • Page 22 Anchorage Fittings For cars not fitted with a child restraint anchorage point For Sedans Only Drill a 9mm diameter hole in the parcel shelf on the centre line of the seating position as shown in Figure 1C. Hole must be no closer than 200mm from the front of the back seat.

  • Page 23: Insurers Information

    NOTICE TO INSURANCE COMPANY CHILD RESTRAINT INVOLVED IN AN ACCIDENT All InfaSecure child restraints are manufactured to Australian/New Zealand Standards AS/NZS1754 which requires us to advise users of child restraints to "Destroy the entire restraint if it has been in use in a severe crash, even if no damage is obvious".
  • Page 24 Notes:...
  • Page 25 Notes:...
  • Page 26 Notes:...

  • Page 27: Lifetime Warranty

    Please visit infasecure.com.au/warranty-registration to register your product. InfaSecure Warranty InfaSecure Pty Ltd warrants this product for twelve months from the date of purchase against failure due to manufacturing faults or faulty materials. Misuse, accidental damages, normal wear and tear are not covered by this warranty.
  • Page 28 ” and advice to keep our little ones safe. INFASECURE PTY LTD ABN: 52 149 173 660 Head Office and Registered Address 110-114 Old Bathurst Rd, Emu Plains, NSW 2750 P.O. Box 487, Emu Plains, NSW 2750...
