JAE TX25 Connector (CN1)

Pin Signal
1 DDP_3N
4 DDP_2N
7 DDP_1N
10 DDP_0N
13 DDP_AUXN
16 GND
19 GND
22 GND
25 GND
28 GND
31 DVI_HPD
34 +12V~+19V
37 +12V~+19V
40 +12V~+19V
43 NC
NC
46
49 NC
52 UART_TXD
55 NC
58 NC
61 USB_PP2
64 USB_PP1
67 USB_PP0
70 LINEOUT_R
73 PS_ON#
76 GND
79 GND
Connectors
Pin Signal
2 DDP_3P
5 DDP_2P
8 DDP_1P
11 DDP_0P
14 DDP_AUXP
17 TMDS_CLK-
20 TMDS0-
23 TMDS1-
26 TMDS2-
29 DVI_DDC_DATA
32 GND
35 +12V~+19V
38 +12V~+19V
41 NC
44 NC
47 NC
50 SYS_FAN_CTL
53 GND
56 GND
59 GND
62 GND
65 GND
68 GND
71 NC
74 NC
77 GND
80 GND
OPS830 Series User's Manual
Pin Signal
3 GND
6 GND
9 GND
12 GND
15 DDP_HPD
18 TMDS_CLK+
21 TMDS0+
24 TMDS1+
27 TMDS2+
30 DVI_DDC_CLK
33 +12V~+19V
36 +12V~+19V
39 +12V~+19V
42 NC
45 NC
48 NC
51 UART_RXD
54 NC
57 NC
60 USB_PN2
63 USB_PN1
66 USB_PN0
69 LINEOUT_L
72 PB_DET
75 GND
78 GND
