Reference Design
Display Panel Rear View – Internal
The digital signage OPS830 prototype is based on a 32" display panel with the
functional blocks illustrated in Figure 18. It is mainly a 3-board partitioning design
consisting of the pluggable module, docking board and the panel control board.
