This chapter provides users with detailed description how to set up basic system
configuration through the AMIBIOS8 BIOS setup utility.
3.1

Connectors

Connectors connect this board with other parts of the system. Loose or improper
connection might cause problems. Make sure all connectors are properly and firmly
connected.
Here is a summary table shows you all connectors on the board.
Connector
CN1
CN4
CN5
CN6
CN7
SCN1
SCN3
SCN4
BAT1
LAN1
USB1
SLED1
SLED2
SDIMM1
Connectors
JAE TX25 Connector
CPU FAN
POW ER BUTTON
RESET BUTTON
VGA Connector
PCI-Express Mini Card Connector
Audio LINE-OUT Connector
Audio MIC-IN Connector
Battery Connector
Ethernet Port
USB Port 0/1
HDD LED
Power LED
DDRIII SO-DIMM Connector
