1.2 Typical System Installation

The Voice-over-IP (VoIP) VoIP Indoor Intercom is a SIP endpoint designed to provide VoIP phone
connectivity in a tamper proof and secure package.
Figure 1-2
Door Strike
.
Operations Guide
illustrates how the VoIP Indoor Intercom can be installed as part of a VoIP phone system.
Figure 1-2. Typical Installation—Door Entry/Access Control
1
VoIP Intercom
Warning
Electrical Hazard: The VoIP Intercom enclosure is not rated for any AC voltages.
GENERAL ALERT
Warning
Electrical Hazard: This product should be installed by a licensed electrician
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard: To prevent injury, this apparatus must be securely attached to
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Generic PoE Hub
2 3 4 5 6
VoIP Intercom
930260L
How to Identify This Product
IP Phone
IP PBX Server
CyberData Corporation
Product Overview 2
