CyberData 011111 series Operation Manual page 72

Figure A-1
Figure A-2
GANG BOX
(Not Provided)
Operations Guide
shows how to properly connect the VoIP Intercom.
Figure A-1. Cable Connections
shows a 1-Gang Box and a 2-Gang Box mounting option.
Figure A-2. Gang Box Mounting
(Not Provided)
TWO
EARTH GROUND
HERE
DRYWALL
CUTOUT
EARTH GROUND
CABLE
From
Microphone
to J5
J5
J6
J2
From
Speaker
From
to J6
PushButton
Switch
to J2
SINGLE
GANG BOX DRYWALL
EARTH GROUND
CABLE
MOUNTING SCREW
(4 PIECES PROVIDED)
930260L
CUTOUT
EARTH GROUND
HERE
CyberData Corporation
65
Mount the Intercom
