67
Mount the Intercom
Figure A-4
shows the maximum recommended wall cutout dimensions.
Figure A-4. Maximum Recommended Wall Cutout Dimensions
0.250 [6.4]
0.250 [6.4]
Wall
Cutout
0.250 [6.4]
0.250 [6.4]
Dimensions are in Inch [Millimeter]
Operations Guide
930260L
CyberData Corporation
