CyberData 011111 series Operation Manual page 73

Voip indoor intercom ral 9003, signal white color

Hide thumbs Also See for 011111 series:

Table of Contents

Mount the Intercom

Figure A-3

shows a wall mounting option.

Figure A-3. Wall Mounting Option

PRE-DRILL HOLE ON WALL (4x)

DRYWALL

MOUNTING SCREW & PLASTIC ANCHOR

CUTOUT

(4 Pieces Each Provided)

EARTH GROUND

CABLE

EARTH GROUND

HERE
