2. On the Events page, enter values for the parameters indicated in
Note
Web Page Item
Enable Event Generation
Events
Enable Button Events
Enable Call Start Events
Enable Call Terminated Events
Enable Relay Activated Events
Enable Relay Deactivated Events
Enable Ring Events
Enable Night Ring Events
Enable Multicast Start Events
Enable Multicast Stop Events
Enable Power On Events
Enable Sensor Events
Enable Remote Relay Events
Enable Security Events
Enable 60 Second Heartbeat
Check All
Uncheck All
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-20. Events Configuration Parameters
930935B
Installing the VoIP Indoor Intercom with Keypad
) in the following table shows which web page items will be defined
.
Description
The device will send HTTP POST events to the specified remote
server and port number whenever a certain action takes place.
Select an event type below to generate an HTTP POST event.
When selected, the device will report Call button presses.
When selected, the device will report the start of a SIP call.
When selected, the device will report the end of a SIP call.
When selected, the device will report relay activation.
When selected, the device will report relay deactivation.
When selected, the device will report when it starts ringing upon an
incoming SIP call. A Ring Event will not be generated when Auto-
Answer Incoming Calls is enabled on the Device page.
When selected, the device will report when it starts ringing upon an
incoming SIP call to the Nightringer extension. As a reminder, the
Nightringer extension always rings upon an incoming SIP call and it
is not possible to alter this behavior.
When selected, the device will report when the device starts playing
a multicast audio stream.
When selected, the device will report when the device stops playing
a multicast audio stream.
When selected, the device will report when it boots.
When selected, the device will report when the on-board sensor is
activated.
When selected, the device will report when the remote relay (DSR)
is activated.
When enabled, the device will report when the intrusion sensor is
activated.
When enabled, the device will report a Heartbeat event every 60
seconds. SIP registration is not required to generate Heartbeat
events.
Click on Check All to select all of the events on the page.
Click on Uncheck All to de-select all of the events on the page.
Intercom Setup
Table 2-20.
