Button Tones
Play Button Tones
Note
2.4.6.1 Dial Out Extension Strings and DTMF Tones (using rfc2833)
On the Button Configuration page, dial out extensions support the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Table 2-12. Button Configuration Parameters (continued)
You must click on the Save button and then the Reboot button for the changes to take
effect.
Table 2-13. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 25.
930935B
Installing the VoIP Indoor Intercom with Keypad
Description
Play a tone when the keypad buttons are pressed.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Start button to start a button test.
Click on the Toggle Help button to see a short description
of some of the web page items. First click on the Toggle
Help button, and you will see a question mark (
next to some of the web page items. Move the mouse
pointer to hover over a question mark to see a short
description of a specific web page item.
Intercom Setup
) appear
