GBAS 0-10 VDC Module I/O Assignments

Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
GBAS (0-10 VDC) Analog Input 1 Assignment
NOT ASSIGNED
2. Press the + or - key until the proper value is displayed.
3. Press the ENTER key to confirm this choice.
4. Press the NEXT key to display Generic BAS Analog Input 2 screen.
5. Press the + or - key until the proper value is displayed.
6. Press the ENTER key to confirm each choice.
7. Repeat steps 1-4 to display Generic BAS Analog Input screens 2, 3
& 4
8. Press the NEXT key to advance to the following screen.
The following screen will display if "Indicate selected diag alarms" is
assigned

GBAS (0-10 VDC) Binary Alarm Assignments

Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Assign Diagnostic To Alarm Output
Any Active Diagnostic
1. Press the + or - key until the proper value is displayed. If "YES" is
assigned to "Any Active Diagnostic", pressing the NEXT key will
advance to the "End of Submenu" screen.
Assigning "NO" to the "Any Active Diagnostic" will advance to the
selectable diagnostic screens. See 0-5 active diagnostic list.
2. Press the ENTER key to confirm each choice.
3. Press the NEXT key to scroll through each Active Diagnostic.
RT-SVP04F-EN
(Yes)
System Programming SETUP
Used with: All Units when GBAS 0-
10 VDC Module is installed
Factory Presets: Not Assigned
Possible Values: Not Assigned,
Unocc Zone Cooling SETPOINT,
Occupied Zone heating SETPOINT,
Unoccupied Zone Heating Setpoint,
Supply Air Cooling SEPOINT, Supply
Air Heating SETPOINT, Space Static
Pressure SETPOINT, SA Static
Pressure SETPOINT, Min Outside Air
Flow SETPOINT, Morning Warmup
SETPOINT, Econ Dry Bulb Enable
SETPOINT, Minimum Position
SETPOINT, Occupied Dehumid
SETPOINT, Unoccupied Dehumid
SETPOINT, Supply Air Reheat
SETPOINT, Occupied Humid
SETPOINT, Unoccupied humidity
SETPOINT
Used with: All Units when GBAS 0-
10 VDC module is installed
Factory Presets: Yes
Possible Values: Yes, No--Values:
Refer to the list of active diagnostics
that can be assigned to each of the
five (5) output definitions in the
"Diagnostics Menu" section.
73
