System Configuration
Software Revision Number:
Multiple Compressor Module (MCM)
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Note: "INVALID" shown in upper right corner if software version not valid for unit w/IntelliPak II config
jumper (All following version screens).
Software Revision Number:
GBAS 0-5 VDC Module
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Software Revision Number:
GBAS 0-10 VDC Module
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Software Revision Number:
Ventilation Override (VOM)
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Software Revision Number:
Exhaust/Comp Enthalpy Module
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
Software Revision Number:
Heat Module
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
106
INVALID Used With: Screen always shown on
Ipak II and MCM Installed (DX Cooling)
15.00
Possible Values: Software Revision
Number: See note below; MCM (before
the period): 0-255; MCM (after the
period): 00-99
INVALID Used With: Screen shown only if GBAS
0-5 VDC Module installed
5.0
Possible Values: Software Revision
Number: See note below; Module
(before the period): 0-255; Module
(after the period): 00-99
INVALID Used With: Screen shown only if GBAS
0-10 VDC Module installed
2.00
Possible Values: Software Revision
Number: See note below; Module
(before the period): 0-255; Module
(after the period): 00-99
INVALID Used With: Screen shown only if VOM
module installed
3.00
Possible Values: Software Revision
Number: See note below; VOM (before
the period): 0-255; VOM (after the
period): 00-99
INVALID Used With: Screen shown only if
Comparative Enthalpy, Power Exhaust
11.00
with Statitrac installed
Possible Values: Software Revision
Number: See note below; Module
(before the period): 0-255; Module
(after the period): 00-99
INVALID Used With: Screen shown only if unit is
not Cooling Only and unit is not
11.00
External Heat
Possible Values: Software Revision
Number: See note below; Module
(before the period): 0-255; Module
(after the period): 00-99
